| [size=-1]Form | [size=-1]Stereo power amplifier |
| [size=-1]Effective output (10Hz - 20kHz, both channel simultaneous operation) | [size=-1]150W+150W (6ohms)
110W+110W (8ohms) |
| [size=-1]THD (at the time of an effective output) | [size=-1]0.008% (8ohms) |
| [size=-1]Cross modulation distortion | [size=-1]0.008% (8ohms) |
| [size=-1]Dumping factor | [size=-1]200 (8ohms) |
| [size=-1]Frequency characteristic (1W) | [size=-1]DC-300kHz and +0 -3dB |
| [size=-1]Input sensitivity/input impedance (1kHz) | [size=-1]1V/10kohm |
| [size=-1]SN ratio (A network, a short circuit) | [size=-1]110dB or more |
| [size=-1]Dynamic power | [size=-1]190W (6ohms)
240W (4ohms)
320W (2ohms) |
| [size=-1]�G���x lobe distortion | [size=-1]Below a limit of measurement |
| [size=-1]TIM distortion (SWATOOTH) | [size=-1]Below a limit of measurement |
| [size=-1]Slew rate | [size=-1]150v/microsec |
| [size=-1]Rise time | [size=-1]0.5microsec |
| [size=-1]Channel separation (1kHz) | [size=-1]90dB or more |
| [size=-1]Load impedance | [size=-1]4ohm-16ohm |
| [size=-1]Power source | [size=-1]AC100V, 50Hz/60Hz |
| [size=-1]Power dissipation | [size=-1]360W |
| [size=-1]Dimensions | [size=-1]Width 460x height 174x depth of 480mm |
| [size=-1]Weight | [size=-1]37.0kg |
